TECHNICAL SPECIFICATIONS REF. UNI40
Tapered pole in S235J quality steel (UNI EN 10219/1) with a circular cross-section, galvanized according to CE standards, composed of straight-welded tubes of various heights and diameters to create the different tapers.
Suitable for mounting INNER or TPLuna arms. Above-ground height: 8 meters; planting depth: 80 cm.
Constructed with three tapered sections: the first is 6000 mm long, the second 2000 mm, and the third 800 mm.
The tapers can be covered with ornamental rings (accessory).
Minimum yield strength 235 N/mm², tensile strength 360/510 N/mm², elongation at break 26%. Dimensional tolerances (UNI EN 40/2 – UNI EN 10219/2).
Each tapered section is welded to the next through a certified process, performed in the following stages:
- Insertion of steel reinforcements into the larger diameter of the taper;
- Welding the reinforcements in multiple parts;
- Insertion and welding of the second taper into the first;
- A cap made from galvanized steel sheet is welded to the first taper.
At the base of the pole, there is a 50x150 mm slot for cable entry from the inspection pit, created using a plasma cutting process, and a screw for grounding.
On the first section of the pole, there is an additional 186x45 mm slot, also created via plasma cutting, which houses a 4-pole/3-way terminal block (wire section 1.5÷16 mm²), and a locking inspection door.
The base of the pole is also fitted with a protective heat-shrink sleeve.
DISCLAIMER
The data reported in the product sheets are the official data available at the time of publication and may be subject to change following technical updates made to the products.
The products may exhibit dimensional tolerances resulting from manufacturing processes, with a maximum deviation of 10% from the declared values.
EUROCOMITALIA reserves the right to make changes without prior notice and disclaims all liability for the accuracy and completeness of the content provided.
