Ori Aluminum Street Light with E-light Technology - All Wattages

The ORI model aluminum street light is a FULL CUT-OFF fixture, perfect for street lighting installations.



Standard surge protection up to 6 kV, extendable up to 10 kV.

Power driver with dimming and control capabilities as specified in the technical data sheet.



Available in various wattages, color temperatures, and wiring configurations.

Housing:

 Lightweight, double-shell body made of die-cast aluminum.

Body dimensions: 670 x 310 x 145h mm. Coated with epoxy powder paint over a phosphochromate pre-treatment for excellent resistance to corrosion and weathering.

4mm thick tempered flat glass diffuser.

Perimeter silicone gasket for a perfect seal.

External screws and hardware are made of stainless steel.

Optics:

Crafted from a single block of aluminum to ensure optimal heat dissipation from the LED diode.

Features molded LEDiL IP67 lenses, which are UV-resistant and IK10 impact-rated, with high-precision collimators to focus the light beam.

The circuit board is coated with a special insulating powder for enhanced protection against electrostatic discharge (ESD).

The IP67-rated optical assembly is mounted on the heat sink with a watertight gasket to protect the LED circuits.

The entire LED engine is secured to the lower housing with six M4 stainless steel screws.

This design allows for easy removal of the LED engine for any maintenance operations.

Adjacent to the LED engine, a bracket holds the OT IP66 CL II driver. It is also secured with stainless steel screws, making the entire assembly easily removable and separate from the LED engine.

All electrical connections are well-insulated and located in the lower housing, including two quick-connect plugs: one to disconnect the LED engine from the driver, and another to disconnect the driver from the mains supply.

Finished in anthracite black. Other RAL colors are available upon request.

Dimensions, shapes, and profiles are as specified in the technical drawing, which is an integral part of this project.
