Electric Charging Station for E-scooters and E-bikes

Four-bay electric charging station for E-scooters or E-bikes.


Structure Composed of:

Steel rack module for electric scooters or bicycles; the base module holds 4 vehicles.

Uprights made of Ø 76 mm tubular posts, prepared for ground anchoring.
In the center, a PLUG Module made of a 110 x 110 mm tubular section containing 4 SCHUKO sockets for charging e-scooters or e-bikes.

PLUG Module for e-bike charging station.
Each PLUG includes a Schuko socket for charging and is also equipped with padlock holders, allowing the user to park and secure their vehicle conveniently and safely while it charges.

Technical specifications:
- 4 x Schuko sockets with IP67 protection
- 4 x holders suitable for securing with a padlock (padlocks not provided).
Rated current: 16 A
Rated voltage: 230 V
Rated frequency: 50Hz
Socket type (category): flush-mount socket
Protection rating: IP67

CIRCUIT BREAKER:
- 1 x RCBO (Residual Current Circuit Breaker with Overcurrent Protection) Id 30mA
Tripping time delay: INSTANTANEOUS
Rated current: 25/22 A
Compliant with standard: CEI EN 61008
Indicator light: voltage presence

The module can be placed side-by-side or extended up to a maximum of 6 bays.

Installation and maintenance:
The feet are designed for ground anchoring using M10 steel bolts.
The surfaces are properly protected by a 5P treatment cycle and powder-coated. See specifications on material protection.
Registered design, registered smart technology.

Padlocks not included, we recommend using a "U-lock".
